PRESSURE TESTED PIPE
WELDED & SEAMLESS
PRESSURE TESTED PIPE
PRESSURE TESTED PIPE GRADES (WELDED & SEAMLESS)
| A53 Grade A | A53 Grade B | API5LX42 PSL 2 / CSA GR. 290 CAT 2 | A106 Grade B / CSA Grade 290 CAT 1 | |
|---|---|---|---|---|
| Yield Strength | 30,000 psi | 35,000 psi | 42,000 psi | 35,000 psi |
| Tensile Strength | 48,000 psi | 60,000 psi | 60,200 psi | 60,000 psi |
VARSTEEL REFERENCE GUIDE
PROCESSING CAPABILITIES
PRESSURE TESTED PIPE GRADES (WELDED & SEAMLESS)
| A53 Grade A | A53 Grade B | API5LX42 PSL 2 / CSA GR. 290 CAT 2 | A106 Grade B / CSA Grade 290 CAT 1 | |
|---|---|---|---|---|
| Yield Strength | 30,000 psi | 35,000 psi | 42,000 psi | 35,000 psi |
| Tensile Strength | 48,000 psi | 60,000 psi | 60,200 psi | 60,000 psi |
